The TP-Link Jetstream 8-Port Gigabit PoE Switch (T1500G-10PS/TL-SG2210P) is designed for businesses that require robust networking solutions with Power over Ethernet (PoE) capabilities. This smart managed switch combines high performance, extensive management features, and advanced security protocols, making it an ideal choice for deploying IP cameras, wireless access points, and VoIP phones.

Key Features and Specifications

• PoE Ports: 8 ports compliant with IEEE 802.3af/at standards, providing up to 61W total PoE power budget.
• SFP Slots: 2 SFP slots for flexible uplink options.
• Performance:
  • Switching capacity of 20 Gbps.
  • Packet forwarding rate of 14.88 Mpps.
  • Supports a MAC address table of up to 8K entries.
• VLAN Support: Capable of managing up to 512 VLANs, enhancing network segmentation and security.
• Quality of Service (QoS): L2/L3/L4 QoS features ensure optimal performance for voice and video applications, with support for 8 priority queues.
• Link Aggregation: Allows for increased bandwidth and redundancy by combining multiple ports.
• Management Options: Offers WEB/CLI management modes, SNMP, and RMON for comprehensive network control.
• Security Features: Includes IP-MAC-Port binding, ACLs, port security, DoS defense, DHCP snooping, and 802.1X authentication to protect the network from unauthorized access.

Physical Specifications

• Dimensions: 11.6 x 7.1 x 1.7 inches (294 x 180 x 44 mm).
• Power Supply: Supports a wide range of input voltages (100~240VAC).
• Mounting Options: Rack mountable design for easy integration into existing setups.

FAQs

What devices can be powered by this switch?
The switch can power any device that complies with the IEEE 802.3af/at standards, including IP cameras, access points, and VoIP phones.

Is this switch suitable for a small business?
Yes, its features are tailored for small to medium-sized businesses requiring reliable networking solutions with PoE capabilities.

Can I manage the switch remotely?
Absolutely! The switch supports various management protocols including SNMP and web-based management interfaces.

61 W PoE Budget —— 8נ802.3af/at-compliant PoE+ ports with a total power supply of 61 W
Full Gigabit Ports —— 8× gigabit PoE+ ports and 2× gigabit SFP Slots provide high-speed connections.
Integrated into Omada SDN —— Zero-Touch Provisioning (ZTP), Centralized Cloud Management, and Intelligent Monitoring.
Centralized Management —— Cloud access and Omada app for ultra convenience and easy management.
Robust Security Strategies —— IP-MAC-Port Binding, ACL, Port Security, DoS Defend, Storm Control, DHCP Snooping, 802.1X, Radius Authentication, and more
Optimized Voice and Video Applications —— L2/L3/L4 QoS and IGMP snooping.
Versatile Management —— WEB/CLI managed modes, SNMP, and RMON bring abundant management features.
